铝锻造 1片式轮圈
RI-A
同“SUPER GT”赛事中推出的BBS赛车轮圈完全相同的竞赛设计理念。
凭借同日本国内巅峰赛事“SUPER GT”实战中所推出的BBS轮圈完全相同的设计理念与风格，
打造出该款竞赛级配置的顶级轮圈。
采用抑制轮圈和轮胎空转的防滑漆，配置钢制轴套以保障即使频繁拆装轮圈也不会伤及螺母孔，
诸如此类，通过对细节处的完美打磨，竭尽全力继承极限领域所追求的功能性与可靠性。
INFORMATION 新闻
COLOR 色彩
-
哑古铜（MBZ）
-
麻灰（MGR）
-
金（GL）
-
钻石银（DS）
19inch +5,000 Yen -
钻石黑（DB）
19inch +5,000 Yen
SPEC 规格
| TYPE | SIZE | INSET | H/P.C.D | PFS/BORE | WEIGHT | Without tax |
|---|---|---|---|---|---|---|
| RI-A022 | 16×7.0 | 48 | 5/100.0 | 56 | 5.7kg | ￥67,000 |
| TYPE | SIZE | INSET | H/P.C.D | PFS/BORE | WEIGHT | Without tax |
|---|---|---|---|---|---|---|
| RI-A053 | 17×7.5 | 44 | 5/100.0 | 56 | 6.9kg | ￥89,000 |
| RI-A062 | 17×9.0 | 40 | 5/100.0 | PFS | 7.4kg | ￥95,000 |
| TYPE | SIZE | INSET | H/P.C.D | PFS/BORE | WEIGHT | Without tax |
|---|---|---|---|---|---|---|
| RI-A019 | 18×7.5 | 48 | 5/114.3 | PFS | 8.0kg | ￥95,000 |
| RI-A020 | 18×7.5 | 48 | 5/112.0 | PFS | 7.9kg | ￥95,000 |
| RI-A021 | 18×7.5 | 48 | 5/100.0 | PFS | 7.7kg | ￥95,000 |
| RI-A031 | 18×7.5 | 43 | 5/114.3 | PFS | 8.0kg | ￥95,000 |
| RI-A015 | 18×8.0 | 45 | 5/112.0 | PFS | 8.3kg | ￥97,000 |
| RI-A024 | 18×8.0 | 45 | 5/120.0 | PFS | 8.3kg | ￥97,000 |
| RI-A030 | 18×8.0 | 48 | 5/112.0 | PFS | 8.0kg | ￥97,000 |
| RI-A032 | 18×8.0 | 45 | 5/114.3 | PFS | 8.2kg | ￥97,000 |
| RI-A037 | 18×8.0 | 45 | 5/100.0 | PFS | 7.8kg | ￥97,000 |
| RI-A049 | 18×8.0 | 22 | 5/112.0 | PFS | 8.4kg | ￥97,000 |
| RI-A051 | 18×8.0 | 52 | 5/112.0 | PFS | 7.9kg | ￥97,000 |
| RI-A052 | 18×8.0 | 39 | 5/108.0 | 63.4 | 7.9kg | ￥97,000 |
| RI-A054 | 18×8.0 | 43 | 5/114.3 | PFS | 8.1kg | ￥97,000 |
| RI-A001 | 18×8.5 | 43 | 5/100.0 | PFS | 8.3kg | ￥99,000 |
| RI-A004 | 18×8.5 | 40 | 5/114.3 | PFS | 8.3kg | ￥99,000 |
| RI-A007 | 18×8.5 | 34 | 5/120.0 | PFS | 8.3kg | ￥99,000 |
| RI-A011 | 18×8.5 | 48 | 5/130.0 | 71.6 | 8.4kg | ￥99,000 |
| RI-A017 | 18×8.5 | 35 | 5/114.3 | PFS | 8.2kg | ￥99,000 |
| RI-A023 | 18×8.5 | 45 | 5/112.0 | PFS | 8.4kg | ￥99,000 |
| RI-A026 | 18×8.5 | 43 | 5/108.0 | 63.4 | 8.1kg | ￥99,000 |
| RI-A027 | 18×8.5 | 52 | 5/114.3 | PFS | 8.2kg | ￥99,000 |
| RI-A033 | 18×8.5 | 48 | 5/114.3 | PFS | 8.3kg | ￥99,000 |
| RI-A036 | 18×8.5 | 38 | 5/112.0 | PFS | 8.1kg | ￥99,000 |
| RI-A041 | 18×8.5 | 40 | 5/112.0 | PFS | 8.0kg | ￥99,000 |
| RI-A047 | 18×8.5 | 35 | 5/112.0 | PFS | 8.2kg | ￥99,000 |
| RI-A016 | 18×9.0 | 38 | 5/112.0 | PFS | 8.3kg | ￥101,000 |
| RI-A025 | 18×9.0 | 50 | 5/120.0 | PFS | 8.5kg | ￥101,000 |
| RI-A034 | 18×9.0 | 45 | 5/114.3 | PFS | 8.3kg | ￥101,000 |
| RI-A035 | 18×9.0 | 50 | 5/114.3 | PFS | 8.2kg | ￥101,000 |
| RI-A038 | 18×9.0 | 45 | 5/100.0 | PFS | 8.2kg | ￥101,000 |
| RI-A002 | 18×9.5 | 45 | 5/100.0 | PFS | 8.6kg | ￥103,000 |
| RI-A003 | 18×9.5 | 22 | 5/114.3 | PFS | 8.8kg | ￥103,000 |
| RI-A005 | 18×9.5 | 50 | 5/114.3 | PFS | 8.4kg | ￥103,000 |
| RI-A008 | 18×9.5 | 23 | 5/120.0 | PFS | 8.6kg | ￥103,000 |
| RI-A009 | 18×9.5 | 40 | 5/120.0 | PFS | 8.6kg | ￥103,000 |
| RI-A018 | 18×9.5 | 35 | 5/114.3 | PFS | 8.4kg | ￥103,000 |
| RI-A028 | 18×9.5 | 27 | 5/120.0 | PFS | 8.4kg | ￥103,000 |
| RI-A055 | 18×9.5 | 50 | 5/120.0 | PFS | 8.5kg | ￥103,000 |
| RI-A012 | 18×10.0 | 40 | 5/130.0 | 71.6 | 8.9kg | ￥105,000 |
| RI-A014 | 18×10.0 | 58 | 5/130.0 | 71.6 | 8.9kg | ￥105,000 |
| RI-A045 | 18×10.0 | 25 | 5/120.0 | PFS | 8.9kg | ￥105,000 |
| RI-A061 | 18×10.0 | 50 | 5/120.0 | PFS | 8.9kg | ￥105,000 |
| RI-A006 | 18×10.5 | 18 | 5/114.3 | PFS | 9.2kg | ￥107,000 |
| RI-A010 | 18×10.5 | 25 | 5/120.0 | PFS | 8.9kg | ￥107,000 |
| RI-A029 | 18×10.5 | 37 | 5/120.0 | PFS | 8.8kg | ￥107,000 |
| RI-A046 | 18×10.5 | 22 | 5/120.0 | PFS | 9.1kg | ￥107,000 |
| RI-A013 | 18×11.0 | 50 | 5/130.0 | 71.6 | 9.1kg | ￥109,000 |
| RI-A048 | 18×11.0 | 37 | 5/120.0 | PFS | 9.1kg | ￥109,000 |
| TYPE | SIZE | INSET | H/P.C.D | PFS/BORE | WEIGHT | Without tax |
|---|---|---|---|---|---|---|
| RI-A056 | 19×9.0 | 50 | 5/130.0 | 71.6 | 9.2kg | ￥143,000 |
| RI-A059 | 19×10.5 | 43 | 5/130.0 | 71.6 | 9.7kg | ￥152,000 |
| RI-A057 | 19×12.0 | 45 | 5/130.0 | 71.6 | 10.3kg | ￥161,000 |
| RI-A058 | 19×12.0 | 61 | 5/130.0 | 71.6 | 10.1kg | ￥161,000 |
The products shown in this list cannot be installed on the following vehicles:
- 5H P.C.D/108：
- Volvo XC90 Plug-in Hybrid
- 5H P.C.D/112：
- Mercedes Benz（GL class, GLS class, R350 4MATIC《’12y～》, R550 4MATIC, ML63 4MATIC,S550 Plug-in Hybrid, V class,［W447］, GLE63S 4MATIC , EQC400 , GLE class, [167series]）, Bentley , Maybach（57, 62）, Maybach GLS600, BMW（X5 7-seater, X5 PHV, X7, iX, iX3, ALPINA XB7）and Audi（e-tron）
- 5H P.C.D/120：
- BMW [X5 7-seater, X5 (F15), Active Hybrid X6], Land Rover, Rolls-Royce, Bentley
- 5H P.C.D/130：
- Audi [Q7], Mercedes Benz [G55, G550, G63], Bentley
*Please enquire about Toyota Alphard/Vellfire (40 series) and Lexus LM.
REMARK 备注
| TYPE | REMARK |
|---|---|
| RI-A011 | Use the OEM bolts. |
| RI-A012 | Use the OEM bolts. |
| RI-A013 | Use the OEM bolts. |
| RI-A014 | Use the OEM bolts. |
| RI-A015 | The disc protrudes 10 mm or more from the rim flange edge. |
| RI-A024 | The disc protrudes 10 mm or more from the rim flange edge. |
| RI-A032 | The disc protrudes 10 mm or more from the rim flange edge. |
| RI-A056 | Use the OEM bolts. |
| RI-A057 | Use the OEM bolts. |
| RI-A058 | Use the OEM bolts. |
| RI-A059 | Use the OEM bolts. |
ATTACHMENT 附属零部配件
- 中心盖 (BBS徽标/金）P5624002G
- 气门咀（TR412）
- 螺栓/螺母（使用原厂螺栓/螺母的尺寸不附带）
- 中心环（仅附带PFS规格尺寸）
CAUTION 注意
- 价格不包含税费。产品规格以及价格等事项可能在不另行通知的情况下进行更改。
